Metal Push-to-Connect Air Fitting | Taper Lateral Swiveling Tee | PN23 Series | Nickel-Plated Brass Pneumatic Connector
The PneumaticPlus PN23 Series Taper Lateral Swiveling Tee Fitting is a durable and compact metal push-to-connect air fitting designed to provide directional flexibility in multi-line compressed air and pneumatic systems. Manufactured from nickel-plated brass, this fitting offers excellent corrosion resistance and long-lasting performance in industrial applications.
Its lateral swiveling tee design allows the branch line to rotate for easier routing, while the tapered male thread ensures a secure, leak-free connection to NPT ports. The push-to-connect mechanism allows for tool-free installation, and the stainless steel gripper with an internal O-ring provides a tight, vibration-resistant seal.
Compatible with PA11, PA12, PA6, PE, and PU tubing (95A durometer or higher), the PN23 Series is ideal for air compressors, pneumatic manifolds, automation equipment, and more.
Key Features:
✔ Lateral Swiveling Tee Design – Allows directional flexibility in branch line routing
✔ Tapered Male Thread – Ensures a secure, pressure-resistant NPT connection
✔ Nickel-Plated Brass Construction – Durable and corrosion-resistant for industrial use
✔ Push-to-Connect Technology – Enables fast, tool-free tube installation
✔ Stainless Steel Gripper – Holds tubing securely and resists vibration
✔ Internal O-Ring Seal – Delivers airtight, leak-free performance
✔ Tubing Compatibility – Supports PA, PE, and PU tubing in pneumatic systems
- Recommended Tubings: PA11, PA12, PA6, Polyethylene PE, Polyurethane PU (95 durometer or above)
- Acceptable Tubing Tolerance: +/- .003
- Working Temperature: -4F to 160F
- Working Pressure: Depending on tubings used and always within: 0 PSI to 217 PSI
- Vacuum Rating: to 28 Hg
- Application Fields: Pneumatic Circuits
